Stainless Steel Wedge Wire Screen

Specifications:

Stainless steel wedge wire screen.

Material: Aisi321, 302, 304, 304L, 316 and 316L stainless steel wire, black wire, Al5Cr23, Ni80Cr20, Ni60Cr15 and etc.

Weave: plain dutch, twilled dutch, reverse, five heddle weave.

Characteristics: acid resisting, alkali resisting, heat resisting and wear resisting.

Application: used for industries of mining, oil, chemical, food, phamaceutical, machine making, scientific research, aviation, etc.


Description

Stainless Steel Wedge Wire Screen is a type of screen that is commonly used in a wide range of industries, including the petroleum industry. It is made from high-quality stainless steel, which makes it highly resistant to corrosion, chemicals, and high temperatures. One of the key advantages of Wedge wire screen is its unique design which consists of a V-shaped wire that is welded to a support rod, creating a V-shaped opening. This design provides a high level of strength and durability, making it suitable for use in high-pressure and high-flow applications.

The Wedge wire screen is also easy to clean and maintain, making it an ideal choice for applications where hygiene is important, such as in the food and beverage industry. In the petroleum industry, Wedge wire screen can be used for a wide range of applications including, oil and gas well screens, water treatment plants, chemical processing, and mineral processing.

In summary, Stainless steel Wedge Wire Screen is an ideal solution for the petroleum industry due to its corrosion resistance, durability, chemical resistance, temperature resistance, easy to clean, and it's unique design which provides a high level of strength and durability.


Stainless steel wedge wire screen is one of our best products,it is exported to Russia,Ukraine,Italy,France and other countries in the world. It is Widely used in Neutral chloride environment,oil refining industry,petrochemical and chemical industry,chemical industry transportation pipeline,oil and gas industry,pulp and paper industry,chemical fertilizer industry,urea industry,phosphate fertilizer industry,seawater environment,energy and environment protection industry,light industry and food industry,food and pharmaceutical industry equipment,high strength structure. If you are interested in our Dutch Woven Wire Cloth, please contact us as soon as possible!


Advantages

Advantages of using Stainless Steel Wedge Wire Screen in the petroleum industry include:

1. Corrosion resistance: The stainless steel construction of Wedge Wire Screen makes it highly resistant to corrosion, which is important in harsh environments such as oil and gas wells.

2. Durability: The Wedge wire design is strong and durable, able to withstand high pressures and flows, making it suitable for use in high-pressure and high-flow applications.

3. Chemical resistance: Stainless steel is resistant to many chemicals, making Wedge Wire Screen suitable for use in applications where chemical exposure is likely.

4. Temperature resistance: Stainless steel can withstand high temperatures, making Wedge Wire Screen suitable for use in applications where high temperatures are present, such as in refining and processing of petroleum products.

5. Easy to clean: Wedge wire screen is easy to clean and maintain, making it an ideal material for use in applications where hygiene is important, such as in the food and beverage industry.

6. Unique design: The V-shaped wire welded to support rod creates a V-shaped opening which provides a high level of strength and durability, making it suitable for high-pressure and high-flow applications.

7. Versatility: Wedge wire screen can be used for a wide range of applications including, oil and gas well screens, water treatment plants, chemical processing, and mineral processing.

8. Recyclable: Stainless steel is a recyclable material, making Wedge wire screen an environmentally friendly option for use in the petroleum industry.


Types

Plain weave

Each warp wire and each weft wire passes over and under the next adjacent wire.

Plain dutch weave woven wire cloth has two sizes of wire diameter. The weft wires has thinner wire diameter, which is woven tightly together to provide a tight mesh for filtering. The warp wires has coarser wire diameter, which provides strength to the woven wire cloth.

Twill dutch weave

It is the extension of the twill weave. Each warp wire and each weft wire passes over and under the next two adjacent complementary wires, which is similar as twill weave. The wire diameter of warp wire is larger than weft wire. The mesh count in the weft direction is greater than the warp direction. Dutch twill weave enables the weft wires to be woven more densely and much smaller aperture sizes can be achieved.

Twill dutch weave is capable of supporting greater loads than the dutch weave. It has finer openings than the twilled weave. It is used for filtering heavy materials.

Reverse dutch weave woven wire cloth

Reverse dutch weave woven wire cloth has finer wire diameter in warp wire and coarser wire diameter in weft wire. and the mesh count in the warp wire is larger than the weft wire.



Woven wire mesh with various materials and weaving types has a wide range of applications, which the most common is filtration. Detail applications are in the below.

· Industrial filtration. Industrial filtration need accurate and effective filtration. We can supply the filter discs and sintered filter mesh for high efficiency and fine filtering.

· Food filtration. The woven wire kitchenware has various types for food filtering and sieving, including water, oil and powder.

· Hops and hot breaks filtration. The bazooka screen is mainly used in the kettles, tuns and other containers to filter hops and hot breaks.

· Shielding. The copper woven wire mesh is used for shielding interference and RMI.


Specification

Plain Dutch Woven Wire Cloth
Mesh/Inch
Warp x Weft
Wire Diameter
mm
Weight
kgs/m2
Filtering valueμm
7 x 500.70 x 0.544.50315
8 x 600.55 x 0.453.64280
12 x 640.58 x 0.423.80180
12 x 900.45x 0.302.60160
14 x 880.50 x 0.332.81150
14 x 1000.40 x 0.282.52140
18 x 1000.40 x 0.282.61130
24 x 1100.35 x 0.252.45115
25 x 1400.30 x 0.201.96100
30 x 1500.23 x 0.181.6195
30 x 1600.23 x 0.181.6990
40 x 2000.18 x 0.141.3075
45 x 2200.18 x 0.1251.2256
50 x 2500.14 x 0.111.0060
50 x 2800.14 x 0.100.8445
60 x 3000.14 x 0.090.8040
65 x 3200.12 x 0.0850.7536
70 x 3500.11 x 0.080.7034
70 x 4000.11 x 0.070.6832
80 x 4000.12 x 0.070.5535


 Twill Dutch Woven Wire Cloth
Mesh/Inch
Warp x Weft
Wire Diameter
mm
Weight
kgs/m2
Filtering valueμm
μm

20 x 2500.28 x 0.206.5587
30 x 2500.25 x 0.202.9670
80 x 7000.10 x 0.081.3225
80 x 7800.11 x 0.071.1927
100 x 7800.10 x 0.071.2025
100 x 9000.10 x 0.601.0622
100 x 7800.10 x 0.701.2124
120 x 4000.10 x 0.060.6640
120 x 6000.10 x 0.060.8430
120 x 11000.08 x 0.050.8818
165 x 8000.07 x 0.050.7015
165 x 12000.07 x 0.040.6819
165 x 14000.07 x 0.040.7614
200 x 6000.06 x 0.0450.4820
200 x 9000.05 x 0.0350.4023
200 x 14000.07 x 0.040.8010
250 x 20000.04 x 0.0270.468
280 x 22000.035 x 0.0250.426.3
320 x 23000.033 x 0.0240.415
325 x 23000.035 x 0.0250.455
400 x 28000.025 x 0.0200.363
500 x 35000.025 x 0.0150.305



Reverse Dutch Weave Wire Cloth
Mesh/Inch
Warp x Weft
Wire Diameter
Warp x Weft
mm
Wire Diameter
Warp x Weft
inch
Absolute Filter rating
μm

63 x 180.40 x 0.600.0157 x 0.0236220
107 x 200.24 x 0.600.0094 x 0.0236210
130 x 350.20 x 0.400.0079 x 0.015780
132 x 160.24 x 0.600.0094 x 0.0236200
132 x 320.20 x 0.400.0079 x 0.0157105
140 x 400.19 x 0.380.0075 x 0.015100
170 x 400.20 x 0.450.0079 x 0.0177130
180 x 1200.088 x 0.100.0035 x 0.00475
200 x 1200.08x 0.100.0031 x 0.00470
175 x 400.15 x 0.380.0079 x 0.015770
175 x 500.15 x 0.300.0059 x 0.01260
290 x 750.09 x 0.200.0035 x 0.007955
600 x 1000.04x 0.140.0157 x 0.005525
615 x 1300.04 x 0.130.0157 x 0.005122
615 x 1020.04x 0.160.0157 x 0.006342
625 x 1330.04 x 0.130.0157 x 0.005117
720 x 1500.036 x 0.100.0014 x 0.003917
850 x 1550.03 x 0.100.0012 x 0.00410
Five-heddle Dutch Weave Wire Cloth
Mesh/Inch
Warp x Weft
Wire Diameter
mm
Aperture(mm)Warp x WeftOpen AreaWeightkgs/m2
108 x 590.1600.075 x 0.271201.07
110 x 600.1600.071 x 0.263191.09
38 x 380.1500.518 x 0.518600.43


Welcome to cooperate with us!

Are you looking for a durable and reliable screen for use in the petroleum industry? Look no further than Stainless Steel Wedge Wire Screen!
Our Wedge Wire Screen is made from high-quality stainless steel, which makes it highly resistant to corrosion, chemicals, and high temperatures. Its unique design, consisting of a V-shaped wire welded to a support rod, creates a V-shaped opening that provides a high level of strength and durability, making it suitable for high-pressure and high-flow applications.

In addition, Wedge wire screen is easy to clean and maintain, ensuring that your operations run smoothly and efficiently. Plus, it is environmentally friendly, being fully recyclable. This makes it an excellent choice for companies looking to reduce their environmental impact. Our Wedge Wire Screen can be used for a wide range of applications including, oil and gas well screens, water treatment plants, chemical processing, and mineral processing.

Don't settle for less when it comes to the screens you use in your operations. Choose Stainless Steel Wedge Wire Screen for its reliability, durability, and environmental benefits. Contact us today to learn more about how Wedge Wire Screen can benefit your petroleum operations.
